CYP HDMI Audio Inserter. Insert an external audio signal into HDMI or DVI signal path.
CLUX-11CA - HDMI Audio Inserter
The HDMI™ Audio Inserter from Cypress Technology is a device that lets you insert an external audio signal into your HDMI source. The Cypress device allows you to insert stereo and multi-channel surround sound signals to give users the capability to select their favourite audio format. If you want to enjoy multiple audio formats while extending your audio signal, then the HDMI Audio Inserter from Cypress Technology is a perfect choice.
Features
- Compliant with HDMI v1.3 (with Deep Color Video), HDCP 1.2 and DVI 1.0
- Supports HDMI Sample Rates up to 192kHz
- Supports Optical Sample Rate up to 96kHz
- Supports TMDS clock frequency rate 225MHz
- Supports high-bit-rate (HBR) audio
- HDMI cable distance testing showed that with 1080p 8bit/12bit resolution, the input/output distance is up to 10 meters
- Low power consumption
- 24-bit resolution
